Engineers at Stanford University have devised a new way to generate electricity from sewage using naturally-occurring "wired microbes" as mini power plants, producing electricity as they digest plant and animal waste.
In a paper published today in the Proceedings of the National Academy of Sciences, co-authors Yi Cui, a materials scientist, Craig Criddle, an environmental engineer, and Xing Xie, an interdisciplinary fellow, call their invention a microbial battery.
One day they hope it will be used in places such as sewage treatment plants, or to break down organic pollutants in the "dead zones" of lakes and coastal waters where fertilizer runoff and other organic waste can deplete oxygen levels and suffocate marine life.
At the moment, however, their laboratory prototype is about the size of a D-cell battery and looks like a chemistry experiment, with two electrodes, one positive, the other negative, plunged into a bottle of wastewater.
Inside that murky vial, attached to the negative electrode like barnacles to a ship's hull, an unusual type of bacteria feast on particles of organic waste and produce electricity that is captured by the battery's positive electrode.
"We call it fishing for electrons," said Criddle, a professor in the department of civil and environmental engineering.
Scientists have long known of the existence of what they call exoelectrogenic microbes – organisms that evolved in airless environments and developed the ability to react with oxide minerals rather than breathe oxygen as we do to convert organic nutrients into biological fuel.
During the past dozen years or so, several research groups have tried various ways to use these microbes as bio-generators, but tapping this energy efficiently has proven challenging.
What is new about the microbial battery is a simple yet efficient design that puts these exoelectrogenic bacteria to work.
The release describes nature of these microbes; more than 100 can fit side by side in the width of a human hair; the microbes are white tubes; they are attached to the carbon filaments of the battery; the tendrils are the "wires" referred to; images were taken by scanning electron microscope.
(Photo Credit: Xing Xie, Stanford University)
At the battery's negative electrode, colonies of wired microbes cling to carbon filaments that serve as efficient electrical conductors. Using a scanning electron microscope, the Stanford team captured images of these microbes attaching milky tendrils to the carbon filaments.
"You can see that the microbes make nanowires to dump off their excess electrons," Criddle said. To put the images into perspective, about 100 of these microbes could fit, side by side, in the width of a human hair.
As these microbes ingest organic matter and convert it into biological fuel, their excess electrons flow into the carbon filaments and across to the positive electrode, which is made of silver oxide, a material that attracts electrons.
The electrons flowing to the positive node gradually reduce the silver oxide to silver, storing the spare electrons in the process. According to Xie, after a day or so the positive electrode has absorbed a full load of electrons and has largely been converted into silver.
At that point it is removed from the battery and re-oxidized back to silver oxide, releasing the stored electrons.
The Stanford engineers estimate that the microbial battery can extract about 30 percent of the potential energy locked in wastewater. That is roughly the same efficiency at which the best commercially available solar cells convert sunlight into electricity.
The release describes nature of these microbes; more than 100 can fit side by side in the width of a human hair; the microbes are white tubes; they are attached to the carbon filaments of the battery; the tendrils are the "wires" referred to; images were taken by scanning electron microscope.
(Photo Credit: Xing Xie, Stanford University)
Of course, there is far less energy potential in wastewater. Even so, the inventors say the microbial battery is worth pursuing because it could offset some of the electricity now use to treat wastewater. That use currently accounts for about three percent of the total electrical load in developed nations. Most of this electricity goes toward pumping air into wastewater at conventional treatment plants where ordinary bacteria use oxygen in the course of digestion, just like humans and other animals.
Looking ahead, the Stanford engineers say their biggest challenge will be finding a cheap but efficient material for the positive node.
"We demonstrated the principle using silver oxide, but silver is too expensive for use at large scale," said Cui, an associate professor of materials science and engineering. "Though the search is underway for a more practical material, finding a substitute will take time."
Stanford scientists have developed a "battery" that harnesses a special type of microbe to produce electricity by digesting the plant and animal waste dissolved in sewage.
(Photo Credit: Xing Xie,Stanford Engineering)
Source: Stanford School of Engineering
