NASA will launch an inflatable aeroshell/heat shield technology demonstrator on a Black Brant XI sounding rocket July 22 from the agency's launch range at the Wallops Flight Facility in Virginia.
The Inflatable Reentry Vehicle Experiment (IRVE-3) is the third in a series of suborbital flight tests of this new technology.
Technicians will vacuum pack the uninflated 10-foot (3.05 meters) diameter cone of high-tech inner tubes into a 22-inch (56 centimeters) diameter sounding rocket.
During the flight test an on board system will inflate the tubes -- stretching a thermal blanket that covers them -to create an aeroshell or heat shield. That heat shield will protect a payload that consists of four segments including the inflation system, steering mechanisms, telemetry equipment and camera gear.
Engineers checked out the Inflatable Reentry Vehicle Experiment after the successful completion of an inflation system test.
(Photo Credit: NASA/ Sean Smith)
Source: NASA/Goddard Space Flight Center
